Quality Assured Automatic Revolving Door

Origin: Shanghai,China
Brand name :SHANEOK
Usage: Commercial
Open Style: Scrolling
Name: Automatic revolving door
Style: luxury
Size: Customizable
Glass: Tempered glass
  • SHANEOK
Availability:
Quantity:
Product Description

1 (2)

1 (14)

1 (16)

Specification
Top Quality Automatic Revolving Door
Power supply
50Hz, 220V
Servo motor
180W
Light
270W
Speed
1-4 RPM( manual or auto adjustable)
Noise
<42dB
Torque
<2nm

inner diameter

outer diameter

Canopy Height

door Wing Height
Entrance & Exit Width
3-Wing
4-Wing
3000
3180
300
2200
1400
2030
3200
3380
300
2200
1500
2170
3400
3580
300
2200
1600
2310
3600
3780
300
2200
1700
2450
3800
3980
300
2200
1800
2590
4000
4180
300
2200
1900
2730
4200
4380
300
2200
2000
2870
4800
4980
300
2200
2300
3050
unit:mm

Operation Modes

1. the operations of ZS revolving doors can be manual or automatic.
2. continuous working mode.
3. start/stop mode.

Safety & Protection

1. Anti-clip: there are strip pressure sensors mounted at the entrance /exit columns, once the passenger is bumped by the rotor
wing, the door will stop immediately. Once the person leaves, the door resumes normal speed.
2. Anti-colide: on the top-front of the display case, there's one wide-rang infrared sensor. If the rotor wing approximates near
the passenger, the door will speed down and stop. When the passenger moves forward, the door will resume rotating again.
3. Emergent stop: in case of emergency, just press down the red button and the door will stop immediately. When emergency removed,
turn the button clock wise and the door will return to normal working.
4. Disabled: the disabled button can be used when there's disabled passing-by. The door will keep running one cycle at low speed
to ensure the safety.
